Camaro 1st gen LS swap
Chevrolet · 1967–1969
Kits listed by vendorsF-body 1st gen
Vendors make swap kits for this vehicle (see below), but we don't have a complete sourced parts list for the whole build yet. Below is what the sources say, the parts vendors list for it, and the guides that apply to every LS swap.
Step by step for the Camaro 1st gen
What this vehicle needs at each stage, from 15 sourced facts, our parts list and 1 owner questions from the forums. Plan your exact combination →
We may earn a commission when you buy through links on this page.
Before you buy
- Mounts, crossmember & oil pan Well sourced
Decide where the engine sits (kit mounts or custom), then measure from the pan rail to the crossmember and to the ground before you choose an oil pan. - Transmission & driveline Partly sourced
Decide which transmission handles your torque and how it will be controlled, then plan the crossmember, driveshaft length and flexplate or bellhousing to match. - Accessories & cooling Well sourced
Decide one accessory drive spacing, and match the balancer, water pump and brackets to it. Then check fan, hose and hood clearance. - Exhaust Partly sourced
Decide headers or manifolds that clear the steering, frame and starter where your mounts put the engine.
2Mounts, crossmember & oil pan
Decide: where the engine sits (kit mounts or custom), then measure from the pan rail to the crossmember and to the ground before you choose an oil pan.
What the sources say for this vehicle:
- The Holley 302-2 LS swap oil pan has a depth of 5.46 in.
- The Holley 302-2 LS swap oil pan holds 5.7 qt in the sump, 6.2 qt total with the stock oil filter.
- The Holley 302-2 LS swap oil pan is not stroker-clearanced and fits a maximum 3.62 in stroke with OE rods.
- Speedway Motors sells the Holley 302-2 LS swap oil pan for $499.95 each and lists it in stock. (as listed 2026-09-30)
- The Dirty Dingo DD-LS-DOUBLE-D-S steel conversion mounts require modification to the clamshell if not installed in the very front holes for OEM location.
- The Dirty Dingo DD-SLIDER adjustable SBC/BBC-to-LS engine mounts are not compatible with low-mount air conditioning.
- The painted Hooker 70101508HKR headers are designed only for vehicles with a stock front subframe and stock steering/suspension, and are not compatible with Detroit Speed products.
More: Oil pan guide
Why this step matters: 1 of 1 owner questions about this vehicle
- Which transmission crossmembers and driveshafts work for an LS swap in a first-gen Camaro? Can I reuse my Muncie 4-speed crossmember and driveshaft with a T56 or 4L80E?
3Transmission & driveline
Decide: which transmission handles your torque and how it will be controlled, then plan the crossmember, driveshaft length and flexplate or bellhousing to match.
What the sources say for this vehicle:
- Cold Case CHC547A is a 1967-1969 F-Body LS-swap aluminum performance dual-flow radiator designed to be used with an external trans cooler.
More: Transmission guide
4Accessories & cooling
Decide: one accessory drive spacing, and match the balancer, water pump and brackets to it. Then check fan, hose and hood clearance.
What the sources say for this vehicle:
- The Cold Case CHC547A radiator core uses two 1.25-inch tubes.
- The Cold Case CHC547A radiator has 16 fins per inch.
- The Cold Case CHC547A radiator includes a 1/4-inch NPT steam port.
- Cold Case's CHC547A page lists upper and lower hose sizes as 1.5 inch in the description bullets but as 1.22 inch upper and 1.37 inch lower in the spec table.
- The Cold Case CHC547A radiator carries a limited lifetime warranty.
More: Accessory drive guide
5Exhaust
Decide: headers or manifolds that clear the steering, frame and starter where your mounts put the engine.
What the sources say for this vehicle:
- Berry Performance Sales sells the painted Hooker 70101508HKR long-tube LS swap headers for $999.95, down from $1,124.95. (as listed 2026-09-30)
LS swap parts listed for the Camaro 1st gen
Vendor catalog listings whose titles name this vehicle — a title match, not a fitment guarantee. Prices as of the date shown; confirm fitment with the vendor. How we match parts
| Type | Product | Vendor | Price | Stock | |
|---|---|---|---|---|---|
| Cooling | LS Upper & Lower Radiator Hose Kit - 1967-1969 Chevy Camaro | ICT Billet | $100 checked 2026-09-29 | In stock | Check price & fitment |
| Cooling | LS Lower Radiator Hose - 1967-1969 Chevy Camaro | ICT Billet | $60 checked 2026-09-29 | In stock | Check price & fitment |
| Headers Exhaust | 1967-69 Chevrolet Camaro/Nova 1 5/8" Shorty LS1-LS9 Engine Swap Header with Hi-Temp-Black Coating | PerTronix | $452.97 checked 2026-09-29 | In stock | Check price & fitment |
| Headers Exhaust | 1967-69 Chevrolet Camaro/Nova 1 5/8" Shorty LS1-LS9 Engine Swap Header with Metallic Ceramic Coating | PerTronix | $399 checked 2026-09-29 | In stock | Check price & fitment |
| Headers Exhaust | LS Headers 67-69 Camaro | ICT Billet | $360 checked 2026-09-29 | In stock | Check price & fitment |
| Cooling | LS Upper Radiator Hose - 1967-1969 Chevy Camaro | ICT Billet | $60 checked 2026-09-29 | Out of stock | Check price & fitment |
| Mounts | Transmission Crossmember 67-69 Camaro 4L60E | ICT Billet | $200 checked 2026-09-29 | Out of stock | Check price & fitment |
Swap kit evidence
- ls engine swap mount kit; 67-69 camaro (f-body), 68-74 ... (search title; page returned 406) — Hedman/Trans-Dapt (kit-listed)
Every LS swap also needs
An oil pan that clears
Compare GM LS pans by sump position and depth.
Accessory drive spacing
F-body, car, truck and Corvette offsets.
Fuel system sizing
Injector and pump sizing for your power goal.
A harness, computer and tune
VATS delete, 24x vs 58x, drive-by-wire, harness makers.
A transmission
4L60E to 8HP70 behind an LS.
